A photo of the SL7.1-Micron-Indoor by Diffusion Lighting

SL7.1-Micron-Indoor

Diffusion LED Ribbon

Diffusion LED Strip SL7.1 is a flexible 5mm wide linear LED strip. It is available in custom lengths and can be cut every 7 LED chips (35.5 mm/ 1.5˝).

Custom Cut Only

Features

5 W/m (1.5 W/ft)
LED Watts
184/m (56/ft)
LED/Meter
95+ CRI
LED CRI
24V DC
Power Input
2700K
403 lm/m
123 lm/ft
3000K
433 lm/m
132 lm/ft
3400K
466 lm/m
142 lm/ft
4100K
500 lm/m
152 lm/ft
Custom Kelvins available upon request
Downloads
Diagrams
Tools

Technical Specification

Dimensions 6333674 cm
Wattage

5 W/m (1.5 W/ft)
Voltage

24 Volts DC
Roll Length

Custom Cut Only
LED/Meter

184/m (56/ft)
Dimmable

Yes
Lamp Life

50,000 hrs LM-80
CRI

95 + CRI
IP Rating

IP 20
Environment

Indoor Only
Operating Temp

-40°C to 120°C
Mounting

Surface
Cutting Point

1.5 in
Adhesive

3M Double Coated
Certificate

cUL Listed | E486690
Warranty

5 Year Warranty

Downloads

Diagrams

SL7.1-Micron-Indoor Diagram
A diagram of a Outdoor LED Strip Lighting SL7.1-Micron-Indoor by Diffusion Lighting

Dimensions

SL7.1-Micron-Indoor Dimensions
Length: 38.5 mm (1.5 in)
Width: 5 mm (0.19 in)
Height: 1 mm (0.04 in)
